CMD40L CBM/CSG Drilling Rig

Category： Energy Drilling Rig
Product description：CMD40L hydraulic drilling rig is specially designed for vertical drilling operations in coal-bed methane(CBM, CSG) and water well, with air& mud drilling techniques.
INQUIRY EMAIL

CMD40L hydraulic drilling rig is specially designed for vertical drilling operations in coal-bed methane(CBM, CSG) and water well, with air& mud drilling techniques. It’s especially suitable for drilling water well with 1000m depth. The rig can be trailer mounted, truck mounted or crawler mounted in accordance with drilling conditions.

Features:

● Top drive.
● 6m square rods with diameter 89mm, 102mm, 114mm.

●Premium hydraulic components from Europe / US.

Specifications

Descriptions		Specs
Drilling Depth.	Φ114 rod(q=32kg/m)	1000m
Chassis	Climbing Angle	25%
Chassis	Tracking Speed	1km/hour
Feed System	Pull Force	40t
	Pull Back	14.5tonne
	Fast Pulling Speed	26m/min
	Fast Feed Speed	31m/min
	Slow Feed Speed	8m/min
Top Drive	Torque/RPM	17,000N•M@0-120rpm
Top Drive	Through Hole Dia	89mm
Mast	Height	7.6m
Power System	Engine	Cummins: QSC8.3-C260, efi type
Power System	Engine	Power:194KW
Tooling Beam& Winch	Pull Force	2 tonne
	Beam Rotating Angel	360°
	Stretching in&out	0.7m
Transportation	Dimension	10.52.254(m)
Rig Body	Gross Weight	20 tonne
