The CMD 100 is API certified, hydraulic drilling rig that is specifically designed for vertical or directional drilling operations in shallow oil & gas, coal-bed methane(CBM, CSG) and geothermal, with air, mud or foam drilling techniques. It can also be used for fast mine rescue and core drilling.
Advantages:
● API certified; API
● Truck mounted, compact and rugged design with high mobility;
● Hydraulic top drive provides high torque and infinitely variable speed control;
● Hydraulic drilling feed system provides precise control of weight on bit(WOB) and rate of penetration(ROP);
● Drilling pull down function negates the use of weighted drill string in top hole and directional drilling operations.
● Tilting top drive provides fast, efficient pipe handling by picking up and laying out drill pipe horizontally;
● No cranes are needed in the setup of the rig due to the hydraulic self-erecting mast.
Features:
● 6 x 10, twin steer Carrier able to access remote, harsh terrain.
● Hydraulic drilling system that provides infinitely variable top drive rotation from 0-300 rpm. Precise weight on bit and feed control and pull down functions.
● The top drive is fitted with 2 speed radial piston motors that produce up to 27,500 Nm of torque ideal for large diameter wells. The CMD100 also has an advantage over our competitors of having a max rotation speed 300rpm ideal for coring drilling.
● The top drive can be tilted to an angle of 80°for effective pipe handling and tripping.
● The top drive is fitted with a floating spindle with a travel of102mm to help prevent thread damage to the drill pipe.
● The top drive spindle has a disc Braking system to allow for precise control of directional drilling operations.
● The mast is a Telescopic design with a stroke of 15.2m feed stroke allowing for the use of range III drill pipe and casing.
● Drilling manifolds are provided for to allow air drilling (Reverse circulation and RAB), rotary mud.
● The large internal diameter of the top drive spindle (105mm) allow for the running of drilling tools trough the top
After sale service
Our expert service engineer team is globally available,
Note:
● Choose the correct capacity;
● BOP is an option;
● Pipe handler is an option.
Technical Specifications
|
Feed system
|
|
Max.Pull
|
100t
|
|
Max.Push
|
20t
|
|
Slipbox
|
|
Max Hollow
|
810mm
|
|
Control Panel to Ground ,MAX.
|
2.08m
|
|
Drill head
|
|
Rotation
|
0-100rpm 0-300rpm
|
|
Output torque
|
27,500Nm@0-100rpm 9,700Nm@0-300rpm
|
|
Spindle hollow
|
115mm
|
|
Mast
|
|
Mast length
|
After telescopic：21m Before telescopic：13.2m
|
|
Feed stroke
|
15.2m
|
|
Rods & Casing
|
Ⅲ（38-45”）
|
|
Number of jack legs
|
6
|
|
Dimensions
|
|
Gross weight
|
55t
|
|
L*W*H
|
14.56m×2.95m×4.25m
|
|
Power system
|
|
Model
|
Cummins KTA19-P750
|
|
Power
|
559KW
|
|
Displacement
|
19L
|
|
Winch
|
|
Max. pull
|
4.5T
|
|
Winch cable
|
35m x 16mm
|
|
Air/Mud line
|
|
Mpa
|
21MPa
|
|
Tube Bore
|
3"
|
|
Mud pump
|
Option
|
|
Air compressor
|
Option
|
